Name: Textile Testing Equipment Durable Rotawash Washing Fastness Tester For Textile Materials
Brand: SKYLINE INSTRUMENTS CO.,LTD
SKU: SL-F09
Price: negotiable USD
Availability: InStock

Home Products Textile Testing Equipment

Textile Testing Equipment Durable Rotawash Washing Fastness Tester For Textile Materials

Product Details:

Place of Origin:	China
Brand Name:	SKYLINE
Certification:	Calibration certificate
Model Number:	SL-F09

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	Negotiated
Packaging Details:	Plywood case
Delivery Time:	7 working days
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	3 unit / month

Contact Now

Detailed Product Description

Cup Capacity:	550ml, 1200ml	Spin Speed:	40±2r/min
Temperature Control Range:	0~100℃	Standards:	AATCC/3/28/61/86/132, BS1006, JISL0860
Brand:	SKYLINE	Power:	AC 380V, 50Hz
Highlight:	textile lab equipment , textile testing machines

Textile Testing Equipment Rotawash Color Fastness Tester

Product Introduction

Rotawash Washing Fastness Tester is used for determining color fastness of textile materials to washings. This is attained by mechanically agitating a specimen of textile in contact with pieces of specified adjacent fabrics in soap – soda solution. Before being rinsing and dried. The change in color of specimen and stains of the adjacent fabrics are assessed with standard Grey Scale.
Number of Jars Eight
Volume of each Jar 550 cc (Approx)
Distance of base jars from the axis of rotation 50 mm
Speed of rotation 40 to 45 rpm.
Temperature of Water Bath Ambient of 980 C
Motor ¼ HP 230 V AC.

Testing Standards
IS 687 – 1979, 764 - 1979, 765 – 1979, 3417 – 179, 3417 – 179, Method of determination of Color fastness of textile materials to washing: Test1, Test2, Test 3, Test 4 and Test 5 respectively.

Technical parameters

Cup capacity	550ml, 1200ml (optional)
Spin speed	40±2r/min
Time control range	99.9min
Time control error	<±5s
Temperature control range	0~100℃
Temperature control error	<±2℃
Heating method	Electric heating
Power supply	AC 380V, 50Hz

Rotate Wash Colour Fastness Tester.pdf

How do you measure wash fastness?

The sample is kept in 60⁰C for 30 minutes in Rota Wash Machine. Rinse the sample twice with cold water. Dry at 60⁰C by hanging or by Flat iron pression but temperature should not be more than 150⁰C. Dry the specimen and the change of shade & degree of staining is measured by Grey Scale & Staining Scale.

Textile Testing Equipment Durable Rotawash Washing Fastness Tester For Textile Materials 0

Product Features

1. This wash fastness tester design parameter conform to ISO, BS, AATCC, JIS, and SDC those standards.
2. This washing fastness tester's box and its test cup adopt stainless steel material, it has anti-high temperature,
acid-base, and corrosion functions.
3. Equip with door safety switch, can protect from burning or injured.
4. Equip with procedure time counter, digital temperature controller, auto temperature, and time control, it has alarm
hint while experiment ending.
5. Can customize cup compound mode according to customers' requirements.
